Antenna PCB RO4350B High Frequency 4 Layer ENIG Board
Model: Ro4350B Ceramic Hybrid High Frequency PCB
Layer: 4L
DK: 3.48
Finished Thickness 1.0MM
Copper Thickness: 1OZ
Dielectric Thickness: 0.762mm
Thermal Conductivity: 0.69w/m.k
Flammability: V-O
Surface Treatment: Immersion Gold
Application: Radio Frequency, Microwave Antenna
Material: Rogers RO4350B+FR4 Mixing Press
Layer: 4L
DK: 3.48
Finished Thickness 1.0MM
Copper Thickness: 1OZ
Dielectric Thickness: 0.762mm
Thermal Conductivity: 0.69w/m.k
Flammability: V-O
Surface Treatment: Immersion Gold
Application: Radio Frequency, Microwave Antenna
Material: Rogers RO4350B+FR4 Mixing Press
Compared with external antennas, built-in antennas such as PCB antenna, FPC antenna and LDS antenna have their own unique product forms. These three can not be regarded as differences. each
has its own advantages and applications.
Cellular / WiFi multi band embedded flexible PCB antenna
PCB antenna is widely used in single band module circuit boards such as Bluetooth module, WiFi module and ZigBee module.
Advantages: the cost is very low, and there is no need to debug again after one debugging.
Disadvantages: suitable for single frequency band, such as Bluetooth and WiFi. There will be some deviation in the performance of PCB antennas in different batches.
