Specifications

Turnkey PCBA:PCB+components sourcing+assembly+package+shipment

Layers Range:1-30L

Board Thickness:8.27-275.8mil (0.21-7.0mm)

Base Material:FR-4 / High TG FR-4 / Halogen Free material/Rogers/Arlon/Taconic/Teflon

Surface Finish:HASL, HASL lead free, Immersion Gold, Immersion Tin, Immersion Silver, Hard gold, OSP

Soldermask Colors:Green, Yellow, Black, Blue, White,Red, Matte, semi-matte,Glossy

Min. Hole Size:0.15mm/6mil (mechanical drill), 0.1mm/4mil (laser drill)

Min. Trace Width/Space:2/2mil

Controlled Impedance:Available

Max. Finished Copper Thickness:12 OZ

Supply Ability:300000 Pieces per Month

Lead Time:Prototype: 5 work days. Mass order: 15 work days

PCBA Capabilities

Quantity Prototype&Low Volume PCB Assembly,from 1 Board to 250,is specialty,or up to 1000

Type of Assembly SMT,Thru-hole

Solder Type Water Soluble Solder Paste,Leaded and Lead-Free

Components

Passive Down to 0201 size

BGA and VFBGA

Leadless Chip Carriers/CSP

Double-sided SMT Assembly

Fine Pitch to 0.8mils

BGA Repair and Reball

Part Removal and Replacement

Bare Board Size:Smallest:0.25*0.25 inches

Largest:20*20 inches

File Formate:Gerber files/Bill of Materials/Pick-N-Place file

Types of Service Turn-key,partial turn-key or consignment

Component packaging Cut Tape,Tube,Reels,Loose Parts

Turn Time Same day service to 15 days service

Testing Flying Probe Test,X-ray Inspection AOI Test

PCB assembly process

Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering

-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing
