Product: Microwave Sensor PCB

Materials: FR-4 TG180 IT180A

Quality standard: IPC 6002-II

PCB DK: 4.2-4.7

Layer: 12

Thickness: 1.8mm

Copper Thickness: 1 OZ

Ground technology: ENIG

Application:Automatic Door Sensor

Microwave Sensor PCB  for Automatic Door Sensor

Overview:this product is our company newly developed MS series in a single PCB microwave sensor module.

The product is particularly suited to ultra-thin design of intelligent household appliances, security products, lighting products and other electronics.

This unique circuit structure design, function expansion, the strength of the strong compatibility and high cost performance advantages,

is the leading the market advantage of the single panel module.

Two kinds of output modes:

1, the default output mode: on/cut, namely low level effectively.

2, customize output way: high level effective model (Vout≈Vcc).

Single PCB module,simplifies the making process, economize the make time and cost,

and reduce the product of bad hidden trouble, improve the quality. so, the products have demonstrated the superior market competitiveness.
