Essential details

Model Number:OEM/ODM PCB from US

Place of Origin:Guangdong, China

Brand Name:FasTechCircuit

Base Material:FR-4

Copper Thickness:1oz

Board Thickness:1.6mm,

Min. Hole Size:0.25mm

Min. Line Width:3mi

Min. Line Spacing:3mil

Surface Finishing:ENIG

Board Size:125 x 248 mm

Item:Electronic manufacturing service

Number of Layers:6 layer

Material:FR4/CEM-1/CEM-3/FR1/aluminum

PCB assembly:SMT, DIP

PCB Capacities and Technical Specification

Layer:1 to 30 layer

Material:FR-4,glass epoxy,FR4 High Tg,Rohs compliant,Aluminum,Rogers,etc

PCB type:Rigid,flexible,rigid-flexible

Shape:Any shape: Rectangular,round,slots,cutouts,complex,irregular

Max PCB dimensions:20inch*20inch or 500mm*500mm

Thickness:0.4~6.0mm, Flex 0.01~0.25''

Thickness tolerance:± 10%

Copper thickness:1/2 to 12 OZ

Copper thickness tolerance:± 0.25oz

Surface finish:HASL,Nickle,Imm Gold,Imm Tin,Imm Silver,OSP etc

Solder mask:Green, red,white,yellow,blue,black, Double-sided

Silk screen:White,yellow,black,or negative, Double-sided or single-sided

Silk screen min line width:0.006'' or 0.15mm

Min drill hole diameter:0.01'',0.25mm.or 10 mil

Min trace/gap:0.075mm or 3mil

PCB cutting:Shear,V-score,tab-routed
